Displacement Measuring Setup

Name: Displacement Measuring Setup
Brand: TAMILNADU ENGINEERING INSTRUMENTS
Price: 13000 INR
Availability: InStock

Price 13000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Displacement Measuring Setup Specification

Frequency
50 Hz

Diameter
12 mm (sensor probe)

Resolution
0.001 mm

Protection
IP54 for sensor unit

Measurement Range
0 50 mm

Humidity %
0 to 95% RH non-condensing

Application Media
Linear Displacement Measurement

Capacity
Single channel

Sensor Type
Linear Variable Differential Transformer (LVDT)

Temperature Range
0C to 50C

Equipment Type
Displacement Measuring Setup

Connectivity Type
USB and RS232 output

Material
Stainless Steel (sensor), Powder Coated Steel (main unit)

Power Supply
230V AC, 50 Hz

Power Consumption
10 W

Accuracy
0.01 mm

Display Type
Digital LED Display

Range
0 to 50 mm

Displacement Measuring Setup Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Chennai

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Main Export Market(s)
Asia

Main Domestic Market
Chandigarh, Himachal Pradesh, Manipur, Nagaland, Uttarakhand, Daman and Diu, South India, Central India, North India, East India, West India, Andaman and Nicobar Islands, Andhra Pradesh, Assam, Arunachal Pradesh, Bihar, Goa, Haryana, Jammu and Kashmir, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Mizoram, Meghalaya, Odisha, Punjab, Pondicherry, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, West Bengal, Dadra and Nagar Haveli, Lakshadweep, Uttar Pradesh, Delhi, Gujarat, Chhattisgarh, All India

About Displacement Measuring Setup

Discover a matchless Offer on our trending Displacement Measuring Setup, ace for commercial measurement needs and engineered for resplendent precision. This LVDT-based device features both digital and analog signals (0-10V, 4-20mA optional), factory calibration, and in-line zero adjustment to deliver accuracy of 0.01 mm. Its bench-top design boasts anti-slip feet and IP54 protection for the sensor. With a stainless steel probe, intuitive push-button controls, and digital LED display, this deal is ideal for diverse industries across Indiadealer to exporter!

Commercial Application Versatility: Where Precision Meets Performance

The Displacement Measuring Setup is widely recognized for its use in industrial automation, quality control labs, research facilities, and educational institutions. Its robust construction and superior accuracy support applications such as material testing, component inspection, machine calibration, and linear displacement analyses on metal, polymer, and composite surfaces. Its adaptable design and stainless steel sensor make it suitable for commercial milling, fabrication workshops, and equipment manufacturers, delivering reliable results across numerous sectors.

Sample Availability, Supply, and Certifications: A Global Offer

Sample units are available upon request to facilitate hands-on evaluation before purchase, reinforcing our customer-centric Offer. With robust supply ability, we efficiently cater to both export markets and the domestic mar, serving as a trusted producer and supplier across India. Every unit comes backed with relevant certifications including factory calibration and RoHS Complianceensuring reliability, safety, and credibility in demanding industrial environments worldwide.

FAQs of Displacement Measuring Setup:

Q: How does the LVDT-based measurement principle enhance accuracy in this setup?

A: The Linear Variable Differential Transformer (LVDT) technology ensures highly accurate, contactless measurement by detecting minute linear displacements with a resolution of 0.001 mm and an overall accuracy of 0.01 mm, making the setup ideal for precision-required applications.

Q: What surface types and application areas are best suited for this displacement measuring setup?

A: It is optimized for measuring linear displacement on metal, polymer, and composite materials in industrial automation, quality assurance labs, research environments, and manufacturing floors.

Q: When is in-line zero adjustment or recalibration necessary?

A: In-line zero adjustment and recalibration should be performed before starting a new testing sequence or after relocating the setup, ensuring continued measurement accuracy and reliability.

Q: Where can I request samples or purchase the equipment?

A: Samples and orders are available directly through our extensive dealer, distributor, and supplier network throughout India. Interested clients can request quick samples for initial evaluation.

Q: What is the process for setting up and operating the equipment?

A: Simply position the bench-top setup, connect power, attach the sensor probe, and use the push-button interface to perform zeroing and calibration. The comprehensive user manual guides you through each step for quick and seamless installation and use.

Q: What accessories and documentation come included with this equipment?

A: Each setup includes a sensor probe, a 2-meter connecting cable (extensible), a user manual, and a calibration certificate, ensuring clients have everything needed for immediate installation and use.
