Digital Rotational Viscometer

Name: Digital Rotational Viscometer
Brand: TAMILNADU ENGINEERING INSTRUMENTS
Price: 50000 INR
Availability: InStock

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Digital Rotational Viscometer Specification

Temperature Range
0C to 100C

Frequency
50/60 Hz

Automation Grade
Automatic

Feature
Auto Range Selection, Overload Protection, LCD Backlit Display, Data Output

Capacity
10 mPas to 2,000,000 mPas

Core Components
Microprocessor, Motor, Spindle Set

Voltage
220V 10% AC

Model No
Digital RV-1

Power Source
AC Adapter

Measurement Range
10 mPas to 2,000,000 mPas

Accuracy
1% of full scale

Usage
Laboratory

Equipment Materials
Stainless Steel and ABS

Type
Rotational Viscometer

Display Type
Digital

Dimension (L*W*H)
400 x 350 x 300 mm

Weight
Approx. 7 kg

Sampling Volume
20 ml

Operating System
Stand-alone

Number of Spindles
4 (Standard Accessories)

Spindle Speed Range
0.3 to 100 rpm (variable)

Protection Class
IP20

Data Storage
Up to 30 readings

Ambient Humidity
80% RH

Calibration
Manual / Automatic

Compliance
ISO 2555, ASTM D2196

Power Consumption
60W

Viscosity Unit
mPas, cP

Alarm
Low Viscosity / Overload warning

Interface
RS232 Port

Digital Rotational Viscometer Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Chennai

Delivery Time
2 Week

Main Domestic Market
Dadra and Nagar Haveli, Himachal Pradesh, Manipur, Meghalaya, Andaman and Nicobar Islands, Uttarakhand, Lakshadweep, South India, East India, West India, Assam, Arunachal Pradesh, Bihar, Chandigarh, Delhi, Daman and Diu, Gujarat, Goa, Haryana, Jammu and Kashmir, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Mizoram, Nagaland, Odisha, Pondicherry, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, West Bengal, North India, Punjab, Andhra Pradesh, Central India, Chhattisgarh, Uttar Pradesh, All India

About Digital Rotational Viscometer

Digital Rotational Viscometer

Digital Rotational Viscometer Use the Idea That the Torque Required to Turn an Object in a Fluid Is a Function of the Viscosity of That Fluid. They Measure the Torque Required to Rotate a Disk or Bob in a Fluid at a Known Speed.

Standard Features

Big Ultra Bright Backlight Lcd Display
Direct Reading on Display
Auto Range Function
Temperature Display
Printer & Computer Interface
Data Logger Software (Optional)not Applicable in Wdv- 8

Advanced Measurement Flexibility

With a broad measurement range and variable spindle speeds, the Digital RV-1 viscometer adapts to various sample types. Its auto range selection and overload protection ensure precise results even when dealing with challenging samples, making it suitable for diverse laboratory and industrial applications.

User-Friendly Operation and Compliance

This viscometer features a digital, backlit display for easy readability, and both manual and automatic calibration for versatile operation. Fully compliant with ISO 2555 and ASTM D2196, it guarantees standardized testing protocols for consistent, traceable measurements across industries.

Reliable Data Handling and Connectivity

Up to 30 sample readings can be stored, while RS232 connectivity facilitates seamless data transfer to computers, optimizing workflow and data management. Low maintenance, protected by an IP20 rating, the device is robust and designed for long-term laboratory use.

FAQs of Digital Rotational Viscometer:

Q: How does the Digital Rotational Viscometer ensure accuracy in viscosity measurements?

A: The Digital RV-1 viscometer maintains accuracy through both manual and automatic calibration modes. Its microprocessor-controlled system, 1% of full scale accuracy, and compliance with ISO 2555 and ASTM D2196 further guarantee reliable and standardized results.

Q: What is the recommended process for setting up and using the viscometer?

A: Simply place the instrument on a stable surface, connect it to an AC power source using the adapter, select the suitable spindle, and input the required parameters via the digital control panel. With a minimum sample volume of 20 ml, you can initiate measurement and view results on the LCD display.

Q: When should I use each spindle provided with the instrument?

A: Spindles are chosen based on sample viscosity and measurement range. Lower viscosity samples require smaller spindles, while higher viscosity samples need larger spindles to ensure accurate readings within the specified range of 10 mPas to 2,000,000 mPas.

Q: Where can I access stored data or export measurement results?

A: Results are stored within the device and can be viewed via its digital display. For export, use the integrated RS232 port, which allows data transfer to external computers or compatible software for further analysis or record-keeping.

Q: What are the main benefits of using this viscometer in laboratory environments?

A: Key benefits include high measurement precision, auto range selection, overload protection, alarm functions for operational safety, and data storage capabilities. Its ease of use and robust build, coupled with compliance to international standards, make it ideal for quality control and research laboratories.

Q: How does the viscometer handle temperature variations during measurement?

A: The Digital RV-1 is designed to measure samples within a temperature range of 0C to 100C, allowing accurate viscosity assessment even under varying laboratory conditions.

Q: Is the viscometer suitable for continuous or repetitive testing, and what safeguards are included?

A: Yes, the viscometers design supports repetitive testing with features like overload protection, low viscosity alarms, and a durable ABS/stainless steel construction, ensuring safe and reliable operation for frequent laboratory use.
