Earth Tester

Name: Earth Tester
Brand: TAMILNADU ENGINEERING INSTRUMENTS
Price: 4000 INR
Availability: InStock

Price 4000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Earth Tester Specification

Surface
Powder Coated

Product Type
Earth Tester

General Use
Measurement of earth resistance and soil resistivity

Material
Steel

Type
Analog

Capacity
Measures earth resistance up to 1000 Ohms

Weight (kg)
Approx. 2.5 kg

Computerized
No

Automatic
No

Control System
Manual

Method
Three Terminal or Four Terminal (Wenner Method) measurement

Voltage
Battery Operated, 6V (4 x 1.5V cells)

Dimension (L*W*H)
Approx. 200mm x 150mm x 100mm

Feature
Portable, Rugged Construction, Direct Reading Scale

Color
Gray/Black

Warranty
1 year

Earth Tester Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Chennai

Delivery Time
2 Week

Main Export Market(s)
Asia

Main Domestic Market
Assam, Chandigarh, Himachal Pradesh, Manipur, Uttarakhand, Daman and Diu, Dadra and Nagar Haveli, South India, Central India, North India, East India, West India, Andaman and Nicobar Islands, Andhra Pradesh, Arunachal Pradesh, Bihar, Goa, Haryana, Jammu and Kashmir, Karnataka, Kerala, Lakshadweep, Madhya Pradesh, Mizoram, Meghalaya, Nagaland, Odisha, Punjab, Pondicherry, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, West Bengal, Maharashtra, All India, Delhi, Gujarat, Jharkhand, Chhattisgarh, Uttar Pradesh

About Earth Tester

Earth Tester

Rugged ABS body; Easy to use hand held meter; Ni-cd Re- chargeable cells; Confirms to ISS 9223/1979; Four terminals F1, P1, P2, F2 (to measure earth resistance as well as specific soil resistivity); Lo-Bat or indication appears on display indicating that the cells (batteries) have gone down, which can be recharged by connecting to 230V, 50 Hz AC mains supply through charging cord provided with the instrument
Application: Mextech digital earth resistance tester is designed to measure the resistance if earth used in power circuit; Telecommunications; Railway electrification; Domestic and industrial electrical installations; The tester measures directly the resistance of the earth and also measure the ground resistivity; The study, elegant and compact body makes the instrument portable; Easy to use; Hand-held instrument
Electrical Specifications: Insulation resistance test, more than 25 Mega ohms at 500 V DC between electrical circuit and containing case; Standard Accessories: Carrying case, charging cord, instruction manual, 8 pieces, 1.2V batteries and adopter for rechargeable cells; Optional Accessories (at extra cost): 4 numbers M.S. Spike (18 inch length), 1 number hammer, 4 numbers cable (25 feet), 1 number screwdriver, all packed in one earth testing kit bag specially designed for Waco earth testers
Dual Ranges: 0 - 10 - 1000 OHM, 0 - 5 - 500 OHM

Rugged and Portable Design

Built with powder-coated steel and weighing around 2.5 kg, this Earth Tester is designed for portability and durability, making it suitable for both indoor and outdoor testing environments. The included shoulder strap and carry bag provide added convenience during transportation and use in remote locations.

Accurate Analog Measurement

Featuring a mirrored scale analog meter, the tester ensures precise, direct readings with minimal parallax error. The instrument supports both three and four terminal (Wenner Method) measurements, making it versatile for different soil conditions and installation sites.

Comprehensive Accessories and Safety Compliance

Supplied with essential test rods and connecting wires, the tester is ready for immediate operation. The unit meets IS 9223 safety standards, guaranteeing reliable performance and safety during electrical verification tasks.

FAQs of Earth Tester:

Q: How does the Earth Tester measure earth resistance and soil resistivity?

A: The Earth Tester utilizes either the three-terminal or four-terminal (Wenner Method) configuration, where test rods are inserted into the ground and connected using supplied wires. The analog meter indicates earth resistance directly on its mirrored scale for easy and accurate readings.

Q: What is the maximum earth resistance and insulation resistance this tester can measure?

A: This device can measure earth resistance up to 1000 Ohms and insulation resistance up to 20 Mega Ohms, covering the requirements for most electrical installations and substation applications.

Q: When is it recommended to use this Earth Tester?

A: It is advisable to use this Earth Tester during the installation, inspection, and maintenance of electrical systems, substations, and lightning arrestors to ensure proper grounding and effective protection against electrical faults.

Q: Where can this tester be effectively utilized?

A: This Earth Tester is suitable for use in field and industrial locations across India, such as substations, building sites, and anywhere earth resistance or soil resistivity assessment is required.

Q: What safety standards does the Earth Tester comply with?

A: The tester meets the IS 9223 safety standards, ensuring compliance with national guidelines for reliability and safe operation during earth resistance measurements.

Q: What benefits does the analog mirrored scale provide over digital displays?

A: The mirrored scale minimizes parallax error and enables users to obtain precise direct readings easily, which is particularly beneficial in challenging, outdoor environments.
